Quasonix’ digital multi-mode dual telemetry transmitters provide the flexibility of two high performance, independent transmitters in one package. The standard 2.0 inch by 3.0 inch design includes a single MDM-15 interface as a primary connector for power, clock and data, and serial communications, while providing two separate RF outputs via SMA connectors. This configuration is ideal for two antenna applications that utilize Space-Time Coding (STC) or Frequency Diversity. The transmitters are designed to transmit airborne telemetry data from a test article to ground stations.
A legacy side by side design is employed in applications requiring bands that currently are not available in the Quasonix TIMTER™ Multi-mode Dual Telemetry Transmitter. A new side by side option will be available soon!
At an astonishing 1.3 cubic inches, the nanoTX™ transmitter supports the smallest of airborne platforms with programmable multi-mode operation and as much as 10 Watts of RF output. The smallest ARTM transmitter now available, nanoTXTM is ideal for airborne applications with strict SWAP constraints.
Dare to compare the new 3rd Generation RDMS™ with the proven 2nd Generation model. The highest performing telemetry receiver on the market is available in an elegant, compact 1U rack mount package and a new 3U touchscreen package with dual, 7-inch full color touchscreens. Configurations include one or two channels, a built-in integrated, three-channel spectrum analyzer, automatic AGC zeroing, PCM deframing (header detection/extraction, Sub-Frame ID (SFID) checking/extraction), built-in playback demodulator, combiner IF output, simultaneous TTL and RS-422 outputs, contiguous frequency tuning, adaptive equalizer, and decoding for SOQPSK Space Time Coded and Low Density Parity Check encoded signals.
Complete Receiver – RF to Bits - A single-box solution that includes downconversion, demodulation, and bit synchronization.
Spectrum analyser shows frequency domain view for up to three channels simultaneously.
Space-Time Coding (STC) operates with Quasonix STC-enabled transmitters to eliminate the dropouts caused by transmit antenna pattern nulls due to inter-antenna interference.
Automatic AGC zeroing.
Browser-based remote interface.
Quasonix’ Multi-Mode Compact RDMS™ Telemetry Receiver features an extremely-sensitive RF downconverter integrated with the company's market-leading ARTM demodulator and bit synchronization in a compact 12 cubic inch flight-ready package. When compared to the competition, RDMS offers a remarkable 6 to 8 dB sensitivity advantage. What you choose to do with the extra link margin is up to you.
Quasonix' digital multi-mode telemetry transmitters are the benchmark of the industry, providing unparalleled performance and value, in small, robust, power-efficient packages. The TIMTER™ transmitter, now in its third generation and smaller than ever at 4.1 cubic inches, offers the most versatility with advanced capabilities like L/S/C frequency tuning, and output power up to 25 Watts.
The Antenna Control Units (ACU) are based on a Linux operating system in an Open Source environment. The UI is an ergonomic amalgamation of analog, digital and control buttons. The combination of operating system and programming languages are well matched to the selected platform, making this a very efficient processing entity. The processing bandwidth of the ACU far exceeds the most stringent antenna/pedestal system requirements.We also supply a relational database to aid the operator with fast setup of previously run missions. The tracking demodulation is FPGA based and supports a variety of manual or electronic scan modulations. This demodulator allows for full control/calibration of all receiver AM signals (up to 16 independent receiver input) via the software tools/menus. We can either generate the lobing signals used for SCM feeds or accept the “top-dead-center” synchronization signal from a Conical Scanner feed. The result is a high bandwidth tracking response which is not limited by the demodulator. Remote control and multiple remote viewing instances of the Local ACU are standard features of all our ACUs. The administrative user has the capability of managing the remote viewing and control of any Local ACUs. The ACUs accept slave data from multiple interfaces, and supports inter-ACU communication on the same network. This allows for antennas to slave to the system with the best tracking opportunity. Various ACU systems are available, including pointers, RF trackers, video trackers, … The CDSI ACU has been adapted to many manufacturer's pedestals and controllers. The ACU can either completely replace any type of pedestal controller or connect to existing controller via Ethernet and provide an updated homogeneous system.
The next generation of DBF antenna technology has extended the RF coverage of the antenna from S-band to L/S/C telemetry bands simultaneously. Utilising a tri-band array to demonstrate the first implementation of a new architecture that is called Universal Beamforming Technology (UBT), which can be applied to a wide variety of DBF applications, including communications, radar and telemetry. Partnering with an antenna element provider to demonstrate the following proof-of-concept hardware for a US Government customer:
RF operation 1 – 6 GHz
Scan extent: +/- 90 deg Azimuth and Elevation (with roll-off)
Target acquisition/tracking at <<13 dB EbN0 (the practical limit for zero BER)
Tracking rates > 100 deg./sec.
16 simultaneous dual-polarized beams
Error-free bit rates up to 30 Mbps from a flying source (hardware supports 120Mbps)
Optimal (pre-detection) combination
Multipath mitigation due to novel processing approach
FOX is an analog signal transport device that accepts signals in any RF (0.4 – 6 GHz) or IF (0 – 250 MHz) band, moves them over great distances and delivers them to any desired RF (0.4 – 6 GHz) or IF (0 – 250 MHz) frequency at the destination. The basic FOX model provides 2 independent channels of infinitely programmable bandwidth (0.5 – 120 MHz). Some of our customers use it in place of a receiver. Options include 4 simultaneous channels, and analog or digital representations of AM and Signal Strength
Why use FOX?
Operators of legacy equipment (L/S band data sources or receivers for example) can continue using the equipment while operating their RF segment in any band not supported by the legacy equipment (C-band for example). FOX carries the signal meticulously between 2 points (90+ dB dynamic range) and reconstructs it at the destination without any loss of fidelity.
Over 90dB of Dynamic Range
UHF-Band to Lower C-Band (Other bands available)
RF IN -> RF and/or IF Out
2 Simultaneous Signals (4 Channels as an option)
Up to 120MHz Bandwidth per channel
Down/Up Conversion Incorporated
Demodulated Signal Available (AM & AGC Output)
Transport Distance: over 300m
CDSI principals have designed, fabricated, integrated, tested, installed and supported Telemetry systems of various kinds for several customers throughout the world. We are often contacted to upgrade existing systems even though they might have been produced by other vendors. We use CDSI Antenna Control Units (ACUs) with the systems we deliver – whether they are complete products or refurbishment efforts. We fabricate our own feeds, as needed, while our reflectors and positioners are supplied by local suppliers. The remaining components are supplied by vendors that we have used in the past, and are well-known to us. Our systems use Open Source software (Linux) and FPGA-based hardware for a tight connection between operator and hardware. We test our Telemetry systems using our Telemetry Environment Simulator (TES) product. It is a system level tool that was designed to allow fully integrated, mechanically positioned Telemetry systems. The TES records the system response to standard as well as custom target scenarios (e.g. overhead pass, close-range launch) and allows the test engineer to analyze and optimize system response as needed. The TES uses its own angle pick-off that is independent of the pedestal's so the test mechanism is non-invasive to the customer's system.
Our Threat Simulation and Evaluation systems use commercially available sub-systems to the greatest extent possible. Our unique design allows a precise and compact antenna/pedestal to perform better than other systems its size. A collection of multi-band transmit and receive antennas are mounted on the pedestal with power amplifiers on the pedestal's yoke arms. With precise pedestal control we leverage antenna reflector size and closely placed RF transmitters, allowing for an economically-attractive solution with high in-beam power densities.
As part of the solution, CDSI provides analytical services to ensure that our customer's technical requirements are properly addressed. We pride ourselves on elegant solutions for difficult filtering problems when the Evaluation system sensitivity may be impaired due to its vicinity to other high-power RF transmission equipment.
The system is controlled and operated via Open-Source software coordinating this multifaceted system (video tracker, waveform generator, amplifiers, RF sensors).
